Applying Moldings

1 Only available for rooms, uncheck Use panel of the Roof Plane Specification
Floor Default to make the settings that dialog. See “Roof Plane Specification
follow active. Check this box to use the Dialog” on page 798.
defaults set in the Floor Defaults dialog for Molding Profile - Specify the molding
the current floor. See “Current Floor 2 profile(s) and/or symbol molding(s)
Defaults” on page 413.
assigned to the selected object. The Default
Check No Ridge Caps on Selected Edge to Base Molding is a basic rectangular stock
prevent a ridge cap from being created on the profile rather than a profile from the library.
selected edge of a roof plane. Only available • A drop-down list of the Molding pro-
on the RIDGE CAPS panel of the Roof Plane file(s) or symbol(s) assigned to the
Specification dialog. See “Selected Edge” selected object displays here. Select the
on page 214. name of a molding to edit it or remove it
Check No Shadow Boards on Selected from the list.
Edge to prevent shadow boards from being • If multiple objects with different mold-
created on the selected edge of a roof plane. ings assigned to them are selected, a No
Only available on the SHADOW BOARDS Change check box will be available just

909
