PIVOTING WHEEL STINGER Mix and Match
Specifications
Operating Envelopes
Top View
152-3/8”
Operating Envelope
72”
30”
32”
Direction
of Travel
Note: A Bell-Hose can not be used if your system has Tire Tracking from a Main Controller, therefore
do not install a Bell-Hose if this is the case.
