EL - 298 Electrical system –circuit
IN Battery harness
DI
EG
TR
AX
FR
ST
Battery positive pole
BR connection post
BW
Battery negative
pole connection
EL post
Battery negative
pole earthed to Battery negative
the vehicle pole connection
frame end
I battery harness - plug & socket connectors for electrical components
I001 To storage battery's positive role I002 To the starter
