Diagnosis - Diagnosis-fault diagnosis of electronic and electrical parts DI - 207
3. Check the radio cassette player IN
Caution
If the assembly of radio cassette player is broken, non-professional personnel normally cannot timely DI
and precisely check and test it. At present often using the substitution judgment method for service
a. Replace with a new or normal radio cassette player EG
b. Connect the circuit, restart the radio cassette player and check if the failure is fixed.
Caution TR
The radio cassette player for replacement must be the same specification as previously used
Is the test result ok? AX
Yes>repair or replace the radio cassette player
Caution FR
It requires professional personnel to perform service for the inside of radio cassette player.
Non-professional personnel shall not dismount. ST
NO>retest the above steps
BR
BW
EL
DI-207
