18-4 LUBRICATION - LUBRICATION SYSTEM
1 Oil Pump Front Cover 13 Gasket Release Spring
2 Dowel Pin 14 Bolt
3 Oil Pump Driving Gear 15 Front Crankshaft Oil Seal
4 Oil Pump Driven Gear 16 Dowel Pin
5 Gasket 17 Oil Cooler Sealing Ring
6 Oil Pressure Switch 18 Oil Cooler
7 Seal Ring 19 Oil Cooler Fixing Bolt
8 Front Cover Gasket of Oil Pump 20 Oil Tray
9 Oil pump cover 21 Oil Drain Bolt
10 Oil Drain Plug 22 Gasket
11 Gasket 23 Oil Tray Gasket
12 Release Plunger
