WIRING - SYSTEM CIRCUIT DIAGRAM 71-83

: component position

NO. Ref. wiring harness NO. Ref. wiring harness

Front instrument Front left door
C003 G002
harness harness
Front instrument Front right door
C037 J003
harness harness

: connectors between wiring harnesses

Ref. wiring harness
NO. NO.
(connector position)
Front instrument harness and
engine compartment harness
C103 A304
(left side of instrument 71
crossbeam)
Front wall instrument harness
C703 J302 and driver door harness
(below the left A pillar)

Front wall instrument harness
C703 G101 and passenger door harness
(below the right A pillar)

: Earthing

NO. Earth point
B2 Left combination instrument
