INSTRUMENT PANEL - DASHBOARD 83-3

1 The instrument cover assembly 14 The air conditioning control panel
2 Panel assembly
3 Copilot side roof moulding 15 Lower left guard board
4 The metal buckle 16 The cover plate of the fuse box
5 The air outlet assembly on the right 17 Engine hood handle assembly
side 18 The plastic buckle
6 The cross recessed self-tapping 19 The air outlet assembly on the left
screw with big half head side
7 The central reinforced stand 20 The cross recessed self-tapping
8 The cross recessed self-tapping screw with big half head
screw with big half head 21 The combination meter baffle
9 Spring nut assembly
10 The glove box assembly 22 The diagnostic unit stand
11 The outer plate of door of the glove 23 The plastic buckle
box assembly 24 Audio panel
12 The inner plate of door of the glove 25 The central air outlet assembly on
box assembly the left side
13 Dashboard lower body assembly 26 The central air outlet assembly on
the right side
