83-22 INSTRUMENT PANEL - CONSOLE

1 The beam assembly of the 12 The cross recessed self-tapping
instrument panel screw with big half head
2 Hexagonal flange face bolt 13 Portable ashtray assembly
3 The handle assembly of the 14 The handbrake jacket assembly
secondary instrument panel 15 The handbrake jacket assembly
4 The rubber pad in the second level 16 Hexagonal flange face bolt
storage box of the secondary 17 The rear panel assembly of the
instrument panel secondary instrument panel
5 The cover plate in the secondary 18 The saucer block assembly of the
instrument panel handle secondary instrument panel
6 The handle hinge axis 19 The saucer in the back row
7 The snap ring of the handle hinge 20 The cross recessed self-tapping
axis screw with big half head
8 The body sub-assembly of the 21 The cover of the saucer in the back
secondary instrument panel row
9 The cross recessed pan head
10 Hexagonal flange face bolt-bigger
series
11 The hexagonal flange face bolt
