TABLE OF CONTENTS
INDEX SUBJECT PAGE
Introduction & Table of Contents 1-9
A Tubing - Standard 10
B Tubing - Sanitary 11
C Poly Carbonate Tubing, Sweeps and Sleeves 11-13
D Sweeps – Standard, Short Radius, Chamber, Blind Tee, Miter Elbows 14-28
0
0
E Laterals / Wyes 45 & 30 29-31
0
F Tees – 90 Branch 32-33
G Couplings - Three Bolt Compression 34-37
H Clamps and Accessories 38-41
I Sanitary Fittings And Tubing For Food Processors - Application and Usage 43-49
Clamps - Sanitary 50-52
Ferrule Components - Sanitary 53-61
Hangers - Sanitary 62
J Adapters 63-69
K Cam Locks 70-76
L Snap Closures 77-79
M Hose Stations 80
N Ball Valve (General Purpose) with Tube Tee 81
O Sanitary Valves 82-86
