Page 798 - Quicksilver Accesories Guide 2019

MERCURY RACING PROPELLER TYPE

48-8M0125747 CNC CLEAVER 5 BLADE 15 DEGREE RAKE LAB
15.5 x 27.5 Pitch LH, SS 4 BL High Polished ‑ Forward
48-8M0125746 FINISHED
14.5 x 27.5 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-842945L70 600 HP, 900 HP, 1200 HP and 1550 HP
15.5 x 27 Pitch LH, SS 4 BL High Gloss ‑ Front 822974 Six and 8M drive bushing
822975 Retaining ring
48-842946L70 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
14.5 x 27 Pitch RH, SS 3 BL High Gloss ‑ Rear for SSM Six and M8
48-842943L80 For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
15.8 X 26 Pitch LH, SS 4 BL High Gloss ‑ Front 8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
48-842944L80 Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length. The
14.8 X 26 Pitch RH, SS 3 BL High Gloss ‑ Rear 15 degree rake propellers are designed specifically for step Vee hulls,
48-8M0125745 diameters from 15 inch to 18 inch and pitch from 26 inch to 40 inch
15.8 x 25.5 Pitch LH, SS 4 BL High Polished ‑ Forward (custom order 41 and 42 inch pitch,14.5" diameters and limited 13
48-8M0125744 degree rake available ‑ contact Mercury Racing).
14.8 x 25.5 Pitch RH, SS 3 BL High Gloss ‑ Rear If moving from the old style 5 blade Cleaver to the new style 5 blade
CNC Cleaver generally move up 2 inch of pitch; example if old style was
48-842943L70 17 x 33 move to 17 x 35 CNC Cleaver.
15.8 x 25 Pitch LH, SS 4 BL High Gloss ‑ Front
48-842944L70 As a general rule for every 1 inch of pitch change, the effect will typically
14.8 x 25 Pitch RH, SS 3 BL High Gloss ‑ Rear be 150 RPM change. For every .50 inch of diameter change, the effect
48-842941L80 will typically be 150 RPM change.
16 X 24 Pitch LH, SS 4 BL High Gloss ‑ Front For a complete listing of part numbers see Mercury Racing Propeller
48-842942L80 chart section.
15 X 24 Pitch RH, SS 3 BL High Gloss ‑ Rear MERCURY RACING PROPELLER TYPE
48-8M0125743
16 x 23.5 Pitch LH, SS 4 BL High Gloss ‑Forward CNC CLEAVER 5 BLADE 18 DEGREE RAKE LAB
48-8M0125742
15 x 23.5 Pitch RH, SS 3 BL High Gloss ‑ Rear FINISHED
48-842941L70
16 x 23 Pitch LH, SS 4 BL High Gloss ‑ Front 600 HP, 900 HP, 1200 HP and 1550 HP
48-842942L70 822974 Six and 8M drive bushing
822975 Retaining ring
15 x 23 Pitch RH, SS 3 BL High Gloss ‑ Rear 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
48-8M0073458 for SSM Six and M8
16 x 22 Pitch LH SS 4 BL High Gloss ‑ Front For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
48-8M0073459 8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
15 x 22 Pitch RH SS 3 BL High Gloss ‑ Rear Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length.
48-8M0125741 Custom order 41 and 42 inch pitch available contact Mercury Racing.
16 x 21.5 Pitch LH, SS 4 BL High Gloss ‑ Forward For a complete listing of part numbers see Mercury Racing Propeller
48-8M0125740 chart section.
15 x 21.5 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-842939L70 CNC CLEAVER 5 BLADE 21 DEGREE RAKE LAB
16 x 21 Pitch LH SS 4 BL High Gloss ‑ Front
48-842940L70 FINISHED
15 x 21 Pitch RH SS 3 BL High Gloss ‑ Rear
48-8M0125739 600 HP, 900 HP, 1200 HP and 1550 HP
822974 Six and 8M drive bushing
16 x 20 Pitch LH, SS 4 BL Hogh Gloss ‑ Forward 822975 Retaining ring
48-8M0125738 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
15 x 20 Pitch RH, SS 3 BL High Gloss ‑ Rear for SSM Six and M8
For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length.
Custom order 41 and 42 inch pitch available contact Mercury Racing.
For a complete listing of part numbers see Mercury Racing Propeller
chart section.

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 791
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
