MERCURY RACING PROPELLER CHARTS

Diameter Pitch Lab Finished LH Lab Finished RH Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation Rotation Rotation
15.63 25 48-889965L45 48-889964L45 15.63 26 48-889965L69 48-889964L69
15.3 25 48-889965L44 48-889964L44 15.3 26 48-889965L68 48-889964L68
15.63 26 48-889965L65 48-889964L65 15 26 N.L.A. N.L.A.
15.3 26 48-889965L64 48-889964L64 15.63 27 48-889967L49 48-889966L49
15 26 48-889965L63 48-889964L63 15.3 27 48-889967L48 48-889966L48
15.63 27 48-889967L45 48-889966L45 15.63 28 48-889967L69 48-889966L69
15.3 27 48-889967L44 48-889966L44 15.3 28 48-889967L68 48-889966L68
15.63 28 48-889967L65 48-889966L65 15 28 N.L.A. N.L.A.
15.3 28 48-889967L64 48-889966L64 15.63 29 48-889969L49 48-889968L49
15 28 48-889967L63 48-889966L63 15.3 29 48-889969L48 48-889968L48
15.63 29 48-889969L45 48-889968L45 15.63 30 48-889969L69 48-889968L69
15.3 29 48-889969L44 48-889968L44 15.3 30 48-889969L68 48-889968L68
15.63 30 48-889969L65 48-889968L65 15 30 N.L.A. N.L.A.
15.3 30 48-889969L64 48-889968L64 15.63 31 48-889971L49 48-889970L49
15 30 48-889969L63 48-889968L63 15.3 31 48-889971L48 48-889970L48
15.63 31 48-889971L45 48-889970L45 15.63 32 48-889971L69 48-889970L69
15.3 31 48-889971L44 48-889970L44 15.3 32 48-889971L68 48-889970L68
15.63 32 48-889971L65 48-889970L65 15 32 N.L.A. N.L.A.
15.3 32 48-889971L64 48-889970L64 15.63 33 48-889973L49 48-889972L49
15 32 48-889971L63 48-889970L63 15.3 33 48-889973L48 48-889972L48
15.63 33 48-889973L45 48-889972L45 15.63 34 48-889973L69 48-889972L69
15.3 33 48-889973L44 48-889972L44 15.3 34 48-889973L68 48-889972L68
15.63 34 48-889973L65 48-889972L65 15 34 N.L.A. N.L.A.
15.3 34 48-889973L64 48-889972L64 15.63 35 48-889973L89 48-889972L89
15 34 48-889973L63 48-889972L63 15.3 35 48-889973L88 48-889972L88
15.63 35 48-889973L85 48-889972L85
15.3 35 48-889973L84 48-889972L84 BRAVO THREE XR PRO FINISHED

MAXIMUS SHORT TUBE 5 BLADE SS LAB
MERCURY RACING PROPELLER CHARTS
FINISHED

Maximus Short Tube 5 Blade Stainless Steel Sterndrive
Propeller Chart
Polished Lab Finished. Barrel length 7.875 inches reduces stern lift. Hub Kit Sold
Separately, for Mercury use 835258K2 for 1 inch or 840389K06 for 1.25 inch
propshaft.

Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation
15.63 23 48-889975L49 48-889974L49
15.3 23 48-889975L48 48-889974L48
15.63 24 48-889975L69 48-889974L69
15.3 24 48-889975L68 48-889974L68
15 24 N.L.A. N.L.A.
15.63 25 48-889965L49 48-889964L49
15.3 25 48-889965L48 48-889964L48
