MERCURY RACING PROPELLER CHARTS

MAX 5 ST Lab Finished Propeller Chart MAX 5 ST Lab Finished Propeller Chart

Mercury Racing Lab Finished MAX 5 ST is designed for high performance bass Mercury Racing Lab Finished MAX 5 ST is designed for high performance bass
boats, center consoles and outboard catamarans with elevated engine heights. The boats, center consoles and outboard catamarans with elevated engine heights. The
shortened exhaust barrel enhances performance of lightweight outboard boats by shortened exhaust barrel enhances performance of lightweight outboard boats by
keeping the stern planted for a confidence‑inspired ride, while the 15.25 inch keeping the stern planted for a confidence‑inspired ride, while the 15.25 inch
diameter stays hooked up at extreme engine heights. For the 1.25 inch prop shaft diameter stays hooked up at extreme engine heights. For the 1.25 inch prop shaft
use 840389K06 HD Hub kit and for 1 inch prop shaft use hub kit 835258K2. use 840389K06 HD Hub kit and for 1 inch prop shaft use hub kit 835258K2.
Diameter Pitch Lab Finished LH Lab Finished RH Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation Rotation Rotation
15.25 22.5 48-8M0156495 48-8M0156494 15.25 22.5 48-8M0156495 48-8M0156494
15.25 23 48-8M0156497 48-8M0156496 15.25 23 48-8M0156497 48-8M0156496
15.25 23.5 48-8M0156499 48-8M0156498 15.25 23.5 48-8M0156499 48-8M0156498
15.25 24 48-8M0156501 48-8M0156500 15.25 24 48-8M0156501 48-8M0156500
15.25 24.5 48-8M0156505 48-8M0156504 15.25 24.5 48-8M0156505 48-8M0156504
15.25 25 48-8M0156507 48-8M0156506 15.25 25 48-8M0156507 48-8M0156506
15.25 25.5 48-8M0156509 48-8M0156508 15.25 25.5 48-8M0156509 48-8M0156508
15.25 26 48-8M0156511 48-8M0156510 15.25 26 48-8M0156511 48-8M0156510
15.25 26.5 48-8M0156515 48-8M0156514 15.25 26.5 48-8M0156515 48-8M0156514
15.25 27 48-8M0156517 48-8M0156516 15.25 27 48-8M0156517 48-8M0156516
15.25 27.5 48-8M0156519 48-8M0156518 15.25 27.5 48-8M0156519 48-8M0156518
15.25 28 48-8M0156521 48-8M0156520 15.25 28 48-8M0156521 48-8M0156520
15.25 28.5 48-8M0156525 48-8M0156524 15.25 28.5 48-8M0156525 48-8M0156524
15.25 29 48-8M0156527 48-8M0156526 15.25 29 48-8M0156527 48-8M0156526
15.25 29.5 48-8M0156529 48-8M0156528 15.25 29.5 48-8M0156529 48-8M0156528
15.25 30 48-8M0156531 48-8M0156530 15.25 30 48-8M0156531 48-8M0156530
15.25 30.5 48-8M0156535 48-8M0156534 15.25 30.5 48-8M0156535 48-8M0156534
15.25 31 48-8M0156537 48-8M0156536 15.25 31 48-8M0156537 48-8M0156536
15.25 31.5 48-8M0156539 48-8M0156538 15.25 31.5 48-8M0156539 48-8M0156538
15.25 32 48-8M0156541 48-8M0156540 15.25 32 48-8M0156541 48-8M0156540
15.25 32.5 48-8M0156545 48-8M0156544 15.25 32.5 48-8M0156545 48-8M0156544
15.25 33 48-8M0156547 48-8M0156546 15.25 33 48-8M0156547 48-8M0156546
15.25 33.5 48-8M0156549 48-8M0156548 15.25 33.5 48-8M0156549 48-8M0156548
15.25 34 48-8M0156551 48-8M0156550 15.25 34 48-8M0156551 48-8M0156550

MAX 5 ST LAB FINISHED PROPELLER MAXIMUS LONG TUBE 5 BLADE SS LAB FINISHED MERCURY RACING PROPELLER CHARTS

Maximus Long Tube 5 Blade Stainless Steel Sterndrive
Propeller Chart
Polished Lab Finished. Barrel length 8.5 inches. Hub Kit Sold Separately, for
Mercury use 835258K2 for 1 inch or 840389K06 for 1.25 inch propshaft.

Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation
15.63 23 48-889975L45 48-889974L45
15.3 23 48-889975L44 48-889974L44
15.63 24 48-889975L65 48-889974L65
15.3 24 48-889975L64 48-889974L64
15 24 48-889975L63 48-889974L63
