HM -K SERIES SPECIFICATIONS

TM
TM
Model HM -20 HM -27 HM -35
TM
No. of cell stacks 1set
3
Max. Flow Rate(Nm /h) 20 27 35
Hydrogen
Delivery Pressure 3~10bar operator selected
Production
Purity before Purifier 99.9%, H 2O saturated, O 2<1000ppm
Purity after Purifier 99.999%, Dew point > -75℃
3
Max. Flow Rate(Nm /h) 10 13.5 17.5
Oxygen
Delivery Pressure 2.8~9.8bar operator selected
Production
Purity before Purifier 99.8%, H 2O saturated
3
Conversion HM TM Cell Stack 4.7kWh/Nm H 2
TM
TM
3
TM
TM
Efficiency HM System 5.3kWh/Nm H 2
TM
Voltage 380~480VAC, 3-phase
Power Supply Frequency 50 or 60Hz
Installed Power 160KVA 220KVA 280KVA
Max. Conductivity < 1μS/cm
Feed Water 3
Consumption < 1liter/Nm H 2
Max. Supply Temperature < 35℃
Cooling Water Max. Required Flow(lpm) 40 48 65
Main Heat Load 105watts/lpm H 2
Type 30%KOH in H 2O
Electrolyte
Quantity(liter) 125 140 155
Type N 2 or Inert Gas
3
Purge Gas Average Consumption 1.8Nm for Start-up
Supply Pressure 7~10bar
Type Air or Inert Gas
Instrument 3
Average Consumption 7Nm /h
Gas
Supply Pressure 5~8bar
Operating Location sheltered area
Condition Ambient Temperature 5~35℃
Hydrogen Generation Unit 2250W×2400D×2300H
Dimensions
Electrical Power Supply 1800W×2000D×2000H
Approx. Weight Hydrogen Generation Unit 2200 2450 2750
(kg) Electrical Power Supply 1900
1. Water Treatment System(Reverse Osmosis)
2. Cooling System(Chiller)
Options
3. Flammable Gas Detector
4. Dewpoint Meter

TM
