HM -Q SERIES SPECIFICATIONS

TM
TM
Model HM -54 HM -75 HM -N
TM
No. of cell stacks 2sets 2~6sets
3
Max. Flow Rate(Nm /h) 54 75 100~300
Hydrogen
Delivery Pressure 3~10bar operator selected
Production
Purity before Purifier 99.9%, H 2O saturated, O 2<1000ppm
Purity after Purifier 99.999%, Dew point > -75℃
3
Max. Flow Rate(Nm /h) 27 37.5 50~150
Oxygen
Delivery Pressure 2.8~9.8bar operator selected
Production
Purity before Purifier 99.7%, H 2O saturated
3
Conversion HM TM Cell Stack 4.8kWh/Nm H 2
TM
TM
3
TM
TM
Efficiency HM System 5.5kWh/Nm H 2
TM
Voltage 380~480VAC, 3-phase
Power Supply Frequency 50 or 60Hz
Installed Power 430KVA 600KVA 800~2400KVA
Max. Conductivity < 1μS/cm
Feed Water 3
Consumption < 1liter/Nm H 2
Max. Supply Temperature < 35℃
Cooling Water Max. Required Flow(lpm) 98 135 180~540
Main Heat Load 117watts/lpm H 2
Type 30%KOH in H 2O
Electrolyte
Quantity(liter) 240 330 700~700
Type N 2 or Inert Gas
3
Purge Gas Average Consumption 2.5Nm for Start-up
Supply Pressure 7~10bar
Type Air or Inert Gas
Instrument 3
Average Consumption 10Nm /h
Gas
Supply Pressure 5~8bar
Operating Location sheltered area
Condition Ambient Temperature 5~35℃
Hydrogen Generation Unit 3000W×2800D×2500H
Dimensions
Electrical Power Supply 2000W×2400D×2400H
Approx. Weight Hydrogen Generation Unit 3400 3850 4500
(kg) Electrical Power Supply 3200
1. Water Treatment System(Reverse Osmosis)
2. Cooling System(Chiller)
Options
3. Flammable Gas Detector
4. Dewpoint Meter

TM
HM -Series Hydrogen Generators TEL : +82-31-451-6431, FAX : +82-31-451-6435
