Hose Assembly and Crimping Hose

Permanent Crimp Series 56 CAUTION: There are several different sections for Hose Assembly and A
Crimping. Be sure you are in the section that corresponds to the fitting
series you are using. See Table of Contents for listing.

1 2 3

Inspection Assembly Prep Assembly Tubing
B

Coiled Air Hose & Fittings

Hose – Visually inspect both Insertion Depth – Shown is a 56 Assemble hose – Push hose C
ends of hose for square cut. series fitting. Using Parflex Depth into fitting all the way to depth
Remove any burrs, loose fibers Insertion Block (part# TH9-1-56), insertion mark. (If fitting does not
or wires. mark the hose with the proper readily slide onto hose, perform
insertion depth line. On some the next step.)
fittings such as 56 Series, this
depth is represented by a dashed
or knurled line on the crimp shell.
Transportation

D

Fittings – Verify fitting series Lubrication (as required) – Using Parker VBS or VBL (vise Fittings
corresponds to the selected Using an SAE 20 weight lubri- blocks) and a rubber mallet, tap
hose. Visually inspect fitting(s) cating oil, lightly lubricate inside fitting onto hose until bottom of E
for a through-hole, threads and of hose end. fitting shell is aligned with depth
damage. insertion mark.
Warning
Do not use lubricating oil when
installing fittings on hose used in
oxygen service. When installing
fittings on hose used in oxygen
service, lubricate with a non-oil
based soap solution. Failure to Tooling, Equipment
do so may result in an explosion & Accessories
and personal injury when hose
is used.
F

General Technical

For detailed ordering information, please consult price list or contact Parflex Division. G
