750-660/000-001

4 8-Channel Digital Input Module PROFIsafe V1.3

334

13 14 15 16
Status LEDs
Inputs Error LEDs
T1 I1 T5 I5
Data contacts
9 13
Pulse output 1 Input 5 T1, I1 T5, I5
Input 1 Pulse output 5
T2 I2 T6 I6
10 14
Pulse output 2 Input 6 T2, I2 T6, I6 T1
Input 2 Pulse output 6 +24 V
T3 I3 T7 I7
I1
11 15
Pulse output 3 Input 7 T3, I3 T7, I7
Input 3 Pulse output 7 0 V
T4 I4 T8 I8 T8
12 16 I8
Pulse output 4 Input 8 T4, I4 T8, I8
Input 4 Pulse output 8
750-660 PROFIsafe
Power jumper
contacts
Delivered without miniature WSB markers

Emergency stop buttons, limit sensors, safety interlock switches and other safety The PROFIsafe address can be set using the code switch located on the side.
sensors with contacts can be operated with the PROFIsafe input module
750-660/000-001. An optocoupler provides electrical isolation between the bus and the field side.
The modules have 8 clock sensitive inputs (I1 ... I8) that are fed by 8 differently Individual I/O modules can be arranged in any combination when configuring
clocked outputs (T1 ... T8). the fieldbus node. An arrangement in groups is not necessary.
clock outputs are short-circuit protected. Inputs are continually monitored for Reference the product manual for further information.
cross circuits and voltage supply from separate sources.
When implementing new installations, please consider PROFIsafe V2
The associated LED for each of the 8 input channels indicates the signal state. iPar 750-662/000-003 8-Channel Digital Input Safety Module.
Two red LEDs also indicate internal or external errors.

Description Item No. Pack. Technical Data
Unit
8FDI 24V DC PROFIsafe V1.3 750-660/000-001 1 Inputs I1 ... I8; pulse inputs
Achievable safety classes 8 x Cat. 2/SIL 2 or 4 x Cat. 4/SIL 3
Outputs T1 ... T8: 8 pulse outputs, short circuit proof
Voltage via power jumper contacts 24 V DC (-15 % ... +20 %)
Current via power jumper contacts (max.) 10 A DC
Response times (min ... max) t on (H->L) = 13 ms ... 71 ms
Accessories Item No. Pack. t off (H->L) = 13 ms ... 26 ms
Unit
plus 2 x runtime internal bus
Miniature WSB Quick marking system plus 2 x runtime coupler - PLC
plain 248-501 5 plus runtime PLC
with marking see Section 11 Proof test interval 10 years
Wire connection CAGE CLAMP ®
Cross sections 0.08 mm² ... 2.5 mm² / AWG 28 ... 14
Strip lengths 8 ... 9 mm / 0.33 in
Standards and Approvals Width 24 mm
Weight 98.3 g
Basic standard safety applications IEC 61508, parts 1-7, 1998 und 2000; EMC immunity of interference acc. to EN 61000-6-2
EN 954-1 Cat. 4 EMC emission of interference acc. to EN 61000-6-4
Conformity marking 1
Korea Certification
r UL 508
r ANSI/ISA 12.12.01 Class I, Div. 2, Grp. ABCD, T4
4 TÜV 07 ATEX 554086 X I M2 Ex d I Mb,
II 3 G Ex nA IIC T4 Gc,
II 3 D Ex tc IIIC T135°C Dc
Permissible ambient temperature 0 °C ... +60 °C
IECEx TUN 09.0001 X Ex d I Mb,
Ex nA IIC T4 Gc,
Ex tc IIIC T135°C Dc
Permissible ambient temperature 0 °C ... +60 °C
