Suction Cups for Packaging
Bellows Suction Cups FSGB-R (Rectangular)
PA01019111_inh_EN.pdf Suction area (LxW) from 52 x 25 mm to 80 x 50 mm PA01019111_inh_EN.pdf

container
Designation Code Bellows Suction Cups FSGB-R (Rectangular)
Schmalz - The Company container Abbreviated designation Suction area LxW Material and Connection thread

Example FSGB-R 60x29 NBR-50 G1/8-IG: in mm Shore hardness G1/8-IG
60x29
FSGB-R
NBR-50
Vacuum Knowledge FSGB-R 52x25 NBR-50 G1/8-IG (IG = female (F))
G1/4-AG (AG = male (M))
SI-50
60x29
80x30
80x40
Vacuum Suction Cups container 80x50
Ordering Data Bellows Suction Cups FSGB-R (Rectangular)

Suction cup FSGB-R (elastomer part + connection plate) is delivered assembled. The assembly consists of:
container
Special Grippers • Suction cup of type FGB-R – elastomer part, available in various dimensions (LxW) and materials
• Aluminium support plate – available with various threads
Vacuum Grip- ping Systems Available spare parts: suction cup FGB-R
Available accessories: supporting frames

container
Bellows Suction Cups FSGB-R (Rectangular)
Mounting Elements container Type Suction cup material * / hardness in Shore A SI-50

NBR-50
FSGB-R 52x25 G1/4-AG** 10.01.06.02281 10.01.06.02282
FSGB-R 52x25 G1/8-IG** 10.01.06.02287 10.01.06.02288
Vacuum Generators FSGB-R 60x29 G1/4-AG** 10.01.06.02283 - -
10.01.06.02289
FSGB-R 60x29 G1/8-IG**
FSGB-R 80x30 G1/4-AG*** - 10.01.06.02284
FSGB-R 80x30 G1/8-IG*** - - 10.01.06.02290
10.01.06.02285
FSGB-R 80x40 G1/4-AG***
Valve Technology FSGB-R 80x40 G1/8-IG*** - - 10.01.06.02291
FSGB-R 80x50 G1/4-AG***
10.01.06.02286
FSGB-R 80x50 G1/8-IG*** - 10.01.06.02292
Switches and Monitoring **2.5 folds
*Additional material specifications at beginning of the section "Vacuum Suction Cups"
***3.5 folds

container Ordering Data Spare Parts Bellows Suction Cups FSGB-R
Filters and Connections container Type Suction cup material * / hardness in Shore A

NBR-50 SI-50
FGB-R 52x25** 10.01.06.01115 10.01.06.01116
FGB-R 60x29** 10.01.06.01117 -
Services FGB-R 80x30*** - - 10.01.06.01112
FGB-R 80x40***
10.01.06.01113
FGB-R 80x50*** - 10.01.06.01114
*Additional material specifications at beginning of the section "Vacuum Suction Cups"
Contact **2.5 folds
***3.5 folds
