Feed ejectors
Feed Ejectors SEC
PA01019111_inh_EN.pdf Suction rate from 215 l/min to 8,640 l/min PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Gripping of very porous materials such as foams, textiles, paper Vacuum Knowledge
and various recycling materials
• Conveyance of light solids, such as polystyrene, plastic
granulates, rice or other filling materials
Vacuum Suction Cups
• Exhaust of non-aggressive vapors and gases

Special Grippers

Vacuum Grip- ping Systems
Feed ejectors SEC
container
Design

• Body made of anodized aluminum or stainless steel
Mounting
• Straight vacuum passage Elements
• Compressed air enters at the side (1), through an annular gap

Vacuum Generators

Valve Technology

System design feed ejectors SEC
Switches and
container
Our Highlights... Your Benefits... Monitoring
• Special ejector with straight >Handling of very porous
vacuum passage for very high materials and low-loss trans-
volume flow rates at low port of bulk goods; high effi-
vacuum values ciency Filters and Connections
• Various models with different >Optimum range of sizes for all
performance figures applications

Services

Contact
Vacuum generation with feed ejector SEC for transporting granulates

Index of Products

container
www.schmalz.com/sec
