Overview of Section 5
Vacuum Area Gripping Systems and Vacuum End Effectors
PA01019111_inh_EN.pdf Area Gripping Systems Page PA01019111_inh_EN.pdf

Vacuum Area Gripping Systems 374 Schmalz - The Company
FXP / FMP

• Dimensions: 442 x 130 to Universal gripper for handling workpieces regardless
1,432 x 130 mm* of size, geometry, material and surface. Vacuum Knowledge
• Sealing element: sealing foam,
suction cups
Vacuum Area Gripping Systems 388
Vacuum
FX / FM Suction Cups

• Dimensions: 76 x 22 to Small and flexible universal gripper for handling work-
120 x 60 mm* pieces regardless of size, geometry, material and surface.
• Sealing element: sealing foam,
suction cups Special Grippers
Vacuum Area Gripping Systems 390
Lagengreifsysteme
SBX Vacuum Grip- ping Systems

• Dimensions: 1.040 x 200 to Robust gripper for powerful handling of lumber,
1,250 x 400 mm* planed or glued timber, sheet materials, construction
• Sealing element: sealing foam timber, pallets and crate elements.
Mounting Elements

Vacuum End Effectors

Vacuum End Effectors VEE 394
Vacuum Generators

• Dimensions: 38 x 38 to System components for quick and cost-effective
300 x 200 mm designing of vacuum end effectors for highspeed
• Sealing element: suction cups packaging processes Technology
Valve

Switches and Monitoring

*Customer-specific gripper dimensions on request
