Triton Dehydration Station ® Triton-E

TCM
U.S. Patent 8491785
TCM-FC
Features and Benefits 15 gpm
■ High Dewatering Rates and particulate removal in 56.78 L/min HY-TRAX ®
one system
TWS
■ Simple Controls
■ Reduce fluid recycling cost TMS
■ No expensive vacuum pump to service and SMU
replace
■ Patent Pending mass transfer technology uses TSU
ambient air to optimize and control dewatering
rates TMU
■ Compact, efficient footprint
TPM
■ Remove free and dissolved water
■ Highly effective in low and high humidity TIM
elements
HMG 3010
■ Automatic air bleed on filter housing
ET-100-6
Water contamination in hydraulic systems can severely reduce the life of hydraulic systems and fluids. Description
®
The Triton Dehydration Station is designed to eliminate 100% of free and up to 90% of dissolved water CTU
from small reservoirs, barrels, and gear boxes. Using a patent pending mass transfer process, the Triton
Dehydration Station efficiently removes water and particulate contamination quickly in all environments. EPK
The Triton-E version handles a larger quantity of oil and higher flow rates than the Triton-A (see previous
2 pages). The Triton-E is recommended for up to 1000 gallon reservoirs with low water ingression rates or Trouble
400 gallon reservoirs with high water ingression rates. Check Plus

®
The Triton Dehydration Station uses patent-pending mass transfer dewatering technology. Ambient air Principle of HTB
is conditioned to increase its water holding capability before injecting to the reaction chamber. Fluid is Operation HFS
equally distributed and cascaded down through reticulated media and the conditioned air stream. Water is
transformed to water vapor and is expelled from the unit as a moist air stream. The relative humidity of the MFS, MFD
®
incoming fluid is continually monitored by an integral TestMate Water Sensor (TWS) and displayed
real-time on the control panel in percent saturation.
MFS-HV, MFD-HV
Dimensions: 32”W x 59”L x 70.25” H Specifications MFDBC
Dry Mass: 1000 lbs (453 kg)
AMS, AMD
Inlet Connections: 1-1/2” MJIC
Outlet Connections: 1-1/4” MJIC FS
Flow Rate: 900 gallons/hour or 15 gpm
AMFS
Inlet Pressure: Atmospheric
Outlet Pressure: to 125 psi (8.62 bar) KLC
Fluid Service Temperature: 50° F to 175°F (10°C to 79°C)
KLS, KLD
Fluid Viscosity: 70-2000 SUS (13 -539 cSt), 2500 with heater
Power Supply: 380 V/3/50 Hz,10 amps AKS, AKD
460 V/3/60 Hz, 7 amps
460 V/3/60 Hz, 22.5 amps w/heater LSN, LSA, LSW
575 V/3/60 Hz, 5.5 amps
575 V/3/60 Hz, 18 amps w/heater X Series
Attainable Water Content: < 50 PPM
MTS
Relative Humidity Display: Standard, 0-99% Range
Construction: Base Frame: Carbon Steel Triton-A
Vessel: Stainless Steel
Seals: Viton ® Triton-E
Protection Class: NEMA 2
SVD01

Media Filter Rating DHC (gm) Media Filter Rating DHC (gm) Element SVD
Z1 ß 4.2 ≥1000 55 Z10 ß 10 ≥1000 52 Performance IXU
(c)
(c)
Z3 ß 4.8 ≥1000 57 Z25 ß 24 ≥1000 48 Appendix
(c)
(c)
Z5 ß 6.3 ≥1000 62
(c)
SCHROEDER INDUSTRIES 111 111 111 111
