5 WINSTA MIDI
Cable Assemblies 2 x 1.5 mm² / 3 x 1.5 mm²
198
PVC H05VV-F 3G1.5 2 H05VV-F 2x1.5 3
halogen-free H05Z1Z1-F 3G1.5 2 H05Z1Z1-F 2x1.5 3
250 V/4 kV/3 I 16 A
N
1 Approvals
Length Item No. Item No.
Connecting cable, plug – free end 2 black black
Coding I
N
PE PVC halogen-free
L
1 m 771-5001/148-000 771-5001/156-000
2 m 771-5001/149-000 771-5001/157-000
3 m 771-5001/150-000 771-5001/158-000
<_______48_______> 4 m 771-5001/151-000 771-5001/159-000
<______ 76 ______> > 9 < 5 m 771-5001/152-000 771-5001/160-000
__> 6 m 771-5001/153-000 771-5001/161-000
54,6 ><8 7 m 771-5001/154-000 771-5001/162-000
771-5001/163-000
771-5001/155-000
8 m
<__
<_____________________________________ L _____________________________________>
Length Item No. Item No.
Connecting cable, plug – free end 3 black black
Coding I
DA--
PVC halogen-free
DA+
1 m 771-5001/164-000 771-5001/172-000
2 m 771-5001/165-000 771-5001/173-000
3 m 771-5001/166-000 771-5001/174-000
<______ 48 ______> 4 m 771-5001/167-000 771-5001/175-000
<______ 76 ______> > 9 < 5 m 771-5001/168-000 771-5001/176-000
__> 6 m 771-5001/169-000 771-5001/177-000
54,6 7 m 771-5001/170-000 771-5001/178-000
771-5001/179-000
8 m
771-5001/171-000
<__
<_____________________________________ L _____________________________________>

Info Accessories
Locking lever,for “flying leads”,
manually operated
1 For “International Certification Organizations” and black 770-101 100 (4x25)
“Approvals — User Guide”, white 770-121 100 (4x25)
see pages 300 to 303. Locking lever, for “flying leads”,
Marine approvals (GL, LR, NV) relate exclusively to tool operated
cables approved for marine applications.
black 770-111 100 (4x25)
white 770-131 100 (4x25)
For other cables, please contact factory.
Lockout cap, for plug, separable, 5-pole
yellow 770-360 100
blue Coding I (N 3 L DA- DA+) Coding pin, for plug (A and B coding)

For coding information, see pages 284 to 286. gray 770-401 100
Fire load data available upon request.
