WINSTA — Distribution Boxes 10
®
Motion and Presence Detectors, ESYLUX
1 Input, 5 Outputs, Coding A, B, S 265
Description:
This WINSTA Distribution Box connects to
®
ESYLUX presence detectors. 1 2 3 1 2 3 1 2 L
L PE N N PE L N PE L
I 20 A
N
250 V / 4 kV / 3
Internal wiring: 2.5 mm 2
Pack.
WINSTA 1 2 3 1 2 3 1 2 L Item Color Item No. Unit
®
Distribution Box Distribution box, black 899-631/443-000 1
L PE N N PE L N PE L
Motion and Presence Detectors
1 Input, 2 Lights, 1 Motion Detector, Coding A + S, WINSTA MIDI
®
Description:
This WINSTA Distribution Box connects to
®
one motion detector and two lights.
L PE N L PE N
10
L PE N L 2 1
I 25 A 230 V IN
N
250 V / 4 kV / 3
Internal wiring: 4 mm 2
Pack.
WINSTA L PE N L PE N Item Color Item No. Unit
®
Distribution Box Distribution box, black 899-631/309-000 1
L PE N L 2 1
230 V IN
