WINSTA MINI special 12
®
WINSTA MIDI special
®
Pole Marking 287
Marking
Suffix Number Application
2-Pole 3-Pole 4-Pole 5-Pole
without 1 2 1 2 3 1 2 3 4 1 2 3 4 5 General applications
Standard network appli-
/060-000 L N L 3 N N 3 lL lL‘ N 3 L1 L2 L3
1
2
cations 230 V/400 V
Fan
/062-000 2 PE 1 3 PE 2 1 N PE 3 2 1
Step switching
230 V
/064-000 2L 3 1L L N 3 L 2L 1L
+ switched
without 1 2 1 2 3 1 2 3 4 1 2 3 4 5 General applications
/071-000 U+ X/Y U- U- S U+ X/Y AI / AO 0–10V
Presence detector
/072-000 U- U+ DI AI
incl. light sensor
Control signal
/073-000 1 3 2 1 3 2 3 1 3 2 3 4
incl. ground
without 1 2 1 2 3 1 2 3 4 1 2 3 4 5 General applications
/080-000 I+ I- N 3 L I- I+ SMI bus
/081-000 1 2 5 1 2 5 3 MP-Bus
Standard fieldbus
/082-000 + - + S - N 3 L - +
applications
Distribution connectors and cable assemblies with above-mentioned pole marking are available upon request.
Item number example:
WINSTA MIDI special, plug, 4-pole, light green, with U- U+ DI AI pole marking 770-274/072-000
®
