12 WINSTA ®
Codings
284
WINSTA MINI WINSTA MIDI
®
®
Description
2-Pole 3-Pole 4-Pole 5-Pole 2-Pole 3-Pole 4-Pole 5-Pole
Series 890/891 890/891 890/891 890/891 770/771 770/771 770/771 770/771
Coding A
black
white
N L N 3 L 1 2 3 N 3 2 1 3 N N L N 3 L 1 2 3 N L3 L2 L1 3 N
lL‘ lL
lL‘ lL
e.g., general
applications
Coding E
green
KNX applications
Coding F
light gray
specialty coding
Coding I
blue
– + + – L 3 N DA DA DA DA L 3 N
+ -
+ –
e.g., dimming
Coding L
dark gray
N‘ L‘ L‘ N‘ L 3 N
e.g., emergency power
supply
Coding P
red
N 3 L L3 L2 L1 3 N
e.g., computer applications
(UPS)
Coding Q
green
L PE2 PE1 N L PE3 PE2 PE1 N
“Clean Earth”
applications
Coding R
orange
S LON LON
e.g. LON bus
®
Coding S
brown
L 2 1
e.g., switching applications
