WINSTA   ®                                                                                              11
           Accessories
           Mounting Plate, Markers, Marking Strips                                                                 281
           Mounting plate                     Markers                            Marking strips
           for WINSTA  Distribution Boxes     for 3- to 5-pole plugs and sockets   for WINSTA  MIDI strain relief housing
                   ®
                                                                                        ®
                                              WINSTA  MIDI and WINSTA  MIDI special
                                                   ®
                                                                ®
















                      Item No.      Pack. Unit   Color    Item No.     Pack. Unit           Item No.      Pack. Unit
           Mounting plate                     Marker,                            Self-adhesive marking strips
                                              for manual marking                 on DIN A4 cards,
                                                                                 182 mm long, white
                      770-680        25       white      770-450          50
                                              green      770-450/000-001  50                210-333          1
                                              yellow     770-450/000-002  50     for 770 Series
                                              red        770-450/000-005  50     Strip height: 6 mm (40 x)
                                              blue       770-450/000-006  50     Marking area:
                                              orange     770-450/000-012  50     Strain relief, 3-pole, 28 x 6.5 mm
                                                                                 Strain relief, 4-pole, 38 x 6.5 mm
                                                                                 Strain relief, 5-pole, 48 x 6.5 mm
                                                                                 Strain relief, 6-pole, 62 x 6.5 mm
                                                                                 Marking software:
           Pan-head screw, M5 x 25 mm,                                           smartMARKING
                        secures distribution box to mounting
                        plate                                                    CD-ROM     888-414/101-101  1
                        not offered by WAGO














          Wall-mounted WINSTA  Distribution Box  WINSTA  Distribution Connector with markers
                       ®
                                                  ®

                                                                                 Color      Item No.      Pack. Unit
                                                                                 Self-adhesive marking strips
                                                                                 on DIN A4 cards,
                                                                                 182 mm long, white                11
                    <______190______>                                            for 771 Series   210-334    1


                                                                                 Strip height: 5 mm (48 x)

                                                                                 Strain relief, 3-pole, 22 x 5.2 mm
                      <_____204,36_____>                                         Marking area:
                        <___129___>                                              Strain relief, 4-pole, 32 x 5.2 mm
                                                                                 Strain relief, 5-pole, 42 x 5.2 mm
                    <______190______>  <____150____>  7,12  <_____171______>  25  <_  Marking software:

                                                                                 smartMARKING

                        6,2
                                   6,2
                     > <__    )_<__  > <__ )                                     CD-ROM     888-414/101-101  1
