11 WINSTA ®
Operating Tools
278
Operating tools Operating tools
partially insulated, with partially insulated shaft
for WINSTA MINI Connectors (890 Series) for optimal operation of connectors and IDC mod-
®
and ules (772 Series)
WINSTA MIDI Connectors (770 Series)
®

Color Item No. Pack. Unit Color Item No. Pack. Unit
Operating tool, Operating tool with partially insulated shaft,
2-pole, for WINSTA MINI Connectors type 1, (2.5 x 0.4) mm blade
®
green 890-382 1 green 210-719 1
Operating tool, Operating tool with partially insulated shaft,
®
3-pole, for WINSTA MINI Connectors type 2, (3.5 x 0.5) mm blade
green 890-383 1 green 210-720 1
Operating tool, Operating tool with partially insulated shaft,
®
4-pole, for WINSTA MINI Connectors type 3, (5.5 x 0.8) mm blade
green 890-384 1 green 210-721 1
Operating tool,
5-pole, for WINSTA MINI Connectors Operating tool set with partially insulated shaft,
®
green 890-385 1 consisting of 210-719, 210-720 and 210-721
green 210-722 1

1 2

Color Item No. Pack. Unit Color Item No. Pack. Unit
Operating tool, Operating tool, 1
®
2-pole, for WINSTA MIDI Connectors short version,
green 770-382 1 (6.5 x 1.2) mm blade
Operating tool, green 210-635 1
3-pole, for WINSTA MIDI Connectors
®
green 770-383 1 Operating tool, 2
with insulated shaft,
(6.5 x 1.2) mm blade
green 210-636 1
