WINSTA — Distribution Boxes 10
®
Switching with Latching Relay
Through Wiring (3-Pole), 1 Light, 2 Push-Buttons, Coding A + S, WINSTA MIDI 273
®

Description:

This WINSTA Distribution Box features a
®
latching relay with 2 push-buttons and 1 light. 230 V OUT
L PE N L PE N 1 2 L 1 2 L

14 13

A2 A1
789-570
L PE N
I 25 A / 16 A 230 V IN
N
250 V / 4 kV / 3
Internal wiring: 4 mm / 2.5 mm 2
2
Pack.
WINSTA L PE N L PE N 1 2 L 1 2 L Item Color Item No. Unit
230 V OUT
®
Distribution Box 14 13
A2 A1 Distribution box, black 899-632/138-000 1
789-570
L PE N
230 V IN

4-Channel Radio Receiver with 4 Make Contacts
1 Input, 4 Outputs, Coding A, WINSTA MIDI
®

Description:

This WINSTA Distribution Box features a
®
4-channel radio receiver that switches 4
independent electrical devices. The radio re- N PE L LRN
ceiver processes telegrams from push-buttons antenna
featuring EnOcean radio technology (PTM
modules). The outputs are switched via relay
contacts. 10

K1 K2 K3 K4
µ µ µ µ

N PE L N PE L N PE L N PE L
I 16 A / 4 A A1 A2 A3 A4
N
250 V / 4 kV / 3

Pack.
®
WINSTA N PE L LRN antenna Item Color Item No. Unit
Distribution Box K1 µ K2 µ K3 µ K4 µ Distribution box, black 899-629/101-000 1
N PE L N PE L N PE L N PE L
A1 A2 A3 A4

WINSTA — perfectly plugged!
®
