Question 9:
What safety features does WINSTA provide when designing different circuits, such as
®
GPS (general power supply), SPS (secure power supply) or UPS (uninterruptible power
supply)?

Coding A (black/white), E (green), F (light gray), I (blue), L (dark gray), P (red), Q (green), R (orange) and S (brown) are foolproof to avoid
mistaken plugging.

Question 10:
Are there individual marking options for WINSTA components?
®
Of course, flexible marking is part of a flexible connector system. This is why WINSTA also offers custom solutions.
®
Question 11:
Can I also integrate two relays in a WINSTA Distribution Box in order to control blind
®
motors?

Yes. It is even possible to integrate up to three 6mm-wide relays into a WINSTA Distribution Box.
®
Question 12:

Is the WINSTA system protected against accidental contact?
®
All components of the WINSTA system are protected against accidental contact. This provides maximum safety.
®
Question 13:

Can two electrical circuits (even those with different voltages) be routed in one connec-
tor/cable?

According to VDE 0100 Part 520, this is acceptable when the connector, or all of the wire insulation present in the cable line is rated for the
maximum voltage applied.
Question 14:

What needs to be considered for installations in rooms requiring increased fire protec-
tion?

In accordance with VDE 0100 Part 482.1.11, H07RN-F cables must be used on account of their greater mechanical strength. 1

Question 15:

Is WINSTA intended for applications in open or easily accessible areas?
®
Specialty products are available for such applications (see pages 116 to 119).

12

®
1 WINSTA Cables Assemblies with H07RN-F cables available upon request. WINSTA — perfectly plugged!
®
