Accessories
4 Operating Tools
272 MCS MINI

Operating tool Operating levers Operating tools

with partially insulated shaft for male and female connectors for male and female connectors
Type 1 equipped with CAGE CLAMP ® equipped with CAGE CLAMP ®

Color Item No. Pack. Unit Color Item No. Pack. Unit Color Item No. Pack. Unit
Operating tool with partially insulated shaft, Operating lever, Operating tool,
type 1, (2.5 x 0.4) mm blade 3.5/3.81 mm pin spacing 3.5/3.81 mm pin spacing
210-719 1 white 734-230 100 (4 x 25) white 734-190 100 (4 x 25)

black 734-191 100 (4 x 25) black 734-231 100 (4 x 25)

Conductor termination parallel to CAGE CLAMP® Conductor connected using push-button. Conductor termination parallel to CAGE CLAMP®
actuation. actuation.

Color Item No. Pack. Unit
Operating tool for MCS MINI

red 210-250 1

yellow 210-251 1

Inserting conductors — Operation perpendicular to
conductor entry.

Note: Terminating MCS MINI male and female
connectors with CAGE CLAMP can be performed
®
via 210-250 and 210-251 operating tools.
