12 DIN-Rail Mount PCB Carriers

574

DIN-rail mount PCB carrier DIN-rail mount PCB carrier DIN-rail mount PCB carrier

Size 1 Size 2 Size 2
with cover and end plates

Covering section = L 1
<____________ 71,2 ____________> <__________________________ 100 __________________________>
<_ 25,2 _> <___ 25,2 ___>

<__________________________100 __________________________> <__________ 46 __________>
<_______________ 85 _______________> <____________________________ 106 ____________________________> <_ _ 17 __> <____ 27 ____> <_________________ 70 _________________>
<_ L 1 _> L 2 __> < > <__ L 3 <_______ L 1 ________> <____ L 2 ____> <_______ L 3 _______> <___ 22 ___>

<__________________________ 100 __________________________>
<____________________________ 106 ____________________________>
L = PCB length L = PCB/Cover length
1
1
L = L – 11 mm (L = Carrier base length) L = L – 15,8 mm (L = Base length)
2
1
2
2
2
1
L = L + 2 mm L = L + 2 mm
3 1 3 1
Length Pack. Length Pack. Length Pack.
Item No. Item No. Item No.
Unit Unit Unit
DIN-rail mount PCB carrier, size 1 DIN-rail mount PCB carrier, size 2 DIN-rail mount PCB carrier, size 2
with conver
End plate, size 1 End plate, size 2 End plate, size 2, “high”
288-601 1 288-621 1 288-626 1
Mounting foot for DIN 35 rail Mounting foot for DIN 35 rail Cover, size 2
288-602 1 288-622 1 288-627 1 m 1
Carrier base, size 1 Carrier base, size 2
288-600 1 m 1 288-620 1 m 1
Phillips screw 2.9 x 13* Phillips screw 2.9 x 13*
210-533 25 210-533 25
Marking strips 7.5 x 0.5 mm
translucent 709-196 1 m 1
white 709-198 1 m 1
PCB is not included. PCB is not included. PCB is not included.
Minimum PCB length without carrier base, size 1: L = 11 mm, size 2: L = 15.8 mm
1
1
Free space between base and PCB bottom side: 5 mm
PCB tolerances: 1.5 mm ± 0.2 mm (thickness), ± 0.2 mm (length/width); -0.1/+0.3 for milling contours
Phillips screws*

End plate
Mounting foot
Carrier base

* 2 pcs per lateral cover. Can be used with a module length of 35 mm or higher.
Side covers must be riveted for smaller modules. Rivet length
depends on module length. Rivets are not part of our product line.
