12 Mini-WSB and WMB Marking Systems

572

Horizontal marking Horizontal marking Horizontal marking

Consecutive numbers/letters each strip Consecutive numbers each strip In color

Marking per card Item No. Pack. Unit Marking per card Item No. Pack. Unit Color Item No. Pack. Unit
Mini-WSB marker card, WMB marker card, Item no. suffixes for colored marker cards,
e.g., for 745 and 831 Series e.g., for 745 Series (4 mm /10 mm pin spacing) e.g., for 745 and 831 Series
2
10 strips with 10 markers per card and Serie 831 10 strips with 10 markers per card
10 strips with 10 markers per card
1 – 10 (10x) 248-502 5 cards 1 – 10 (10x) 793-502 5 cards yellow . . ./000-002
11 – 20 (10x) 248-503 5 cards 11 – 20 (10x) 793-503 5 cards red . . ./000-005
21 – 30 (10x) 248-504 5 cards 21 – 30 (10x) 793-504 5 cards blue . . ./000-006
31 – 40 (10x) 248-505 5 cards 31 – 40 (10x) 793-505 5 cards gray . . ./000-007
41 – 50 (10x) 248-506 5 cards 41 – 50 (10x) 793-506 5 cards orange . . ./000-012
51 – 60 (10x) 248-569 5 cards 51 – 60 (10x) 793-569 5 cards light green . . ./000-017
61 – 70 (10x) 248-570 5 cards 61 – 70 (10x) 793-570 5 cards green . . ./000-023
71 – 80 (10x) 248-571 5 cards 71 – 80 (10x) 793-571 5 cards violet . . ./000-024
81 – 90 (10x) 248-572 5 cards 81 – 90 (10x) 793-572 5 cards
91 – 100 (10x) 248-573 5 cards 91 – 100 (10x) 793-573 5 cards Ordering example: Mini-WSB
Marking on yellow card, 41 – 50,
1 – 50 (2x) 248-566 5 cards 1 – 50 (2x) 793-566 5 cards 248-506/000-002
51 – 100 (2x) 248-507 5 cards 51 – 100 (2x) 793-507 5 cards
101 – 150 (2x) 248-508 5 cards 101 – 150 (2x) 793-508 5 cards Ordering example: WMB
151 – 200 (2x) 248-509 5 cards 151 – 200 (2x) 793-509 5 cards 793-506/000-002
201 – 300 (2x) 248-510 5 cards 201 – 300 (2x) 793-510 5 cards
301 – 400 (2x) 248-511 5 cards 301 – 400 (2x) 793-511 5 cards
401 – 500 (2x) 248-512 5 cards 401 – 500 (2x) 793-512 5 cards
501 – 600 (2x) 248-513 5 cards 501 – 600 (2x) 793-513 5 cards
601 – 700 (2x) 248-514 5 cards 601 – 700 (2x) 793-514 5 cards
701 – 800 (2x) 248-515 5 cards 701 – 800 (2x) 793-515 5 cards
801 – 900 (2x) 248-516 5 cards 801 – 900 (2x) 793-516 5 cards
901 – 1000 (2x) 248-517 5 cards 901 – 1000 (2x) 793-517 5 cards
1 – 9, ; (10x) 248-565 5 cards 1 – 9, ; (10x) 793-565 5 cards

U, V, W, N, PE, U, V, W, N, PE; (10x)
248-474 5 cards
L1, L2, L3, N, PE, L1, L2, L3, N, PE; (10x)
248-472 5 cards
plain, for self-marking plain, for self-marking
248-501 5 cards 793-501 5 cards
Note:
Please note that colored marker cards are normally on
Felt-tip pen, for permanent marking 210-110 1
longer delivery and more expensive than standard cards.
