Test and Measurement Tools
12

567

Digital multimeter Digital clamp meter Digital clamp meter

Multi-Tester Amp-Tester Clamp-Multi-Tester

2

Kein Produktbild !! Kein Produktbild !! Kein Produktbild !!

Item No. Pack. Unit Item No. Pack. Unit Item No. Pack. Unit
Multi-Tester, Amp-Tester, Clamp-Multi-Tester,
digital multimeter with non-contact voltage tester, digital clamp meter, digital clamp meter
with bag true RMS measurement, DC and AC current up to 600 A
Measurement range: 600 V AC/DC, 10 A AC/DC with bag True RMS and min./max. value measurement
Resistance measurement: up to 20 MΩ Measurement range: 0.01 – 200 A AC/DC, up to 400 Hz (sinus) DC and AC voltage up to 600 V
Protection class: IP44 Manual or automatic selection of measurement range
206-810 1 206-815 1 206-816 1

Accessory
Replacement test leads, red/black

206-811 1

Additional Multi-Tester features: Additional Amp-Tester features: Additional Clamp-Multi-Tester fearures:
· Contact-less voltage test AC >100 V (optical and · AC and DC current measurement · Resistance up to 60 MΩ
acoustical) · True RMS measurement · Capacitance measurement
· Resistance measurement up to 20 MΩ · Data hold function · Acoustical continuity test
· Acoustical continuity test · Maximum jaw opening: 21 mm Ø · Diode test
· Diode test · Compact design for measuring in tight spaces · Data hold function
· Data hold function · Resolution: 0.01 A at 40 A · Large LCD with backlight
· Auto power-off function · Resolution: 0.1 A at 200 A · LED measuring point lighting
· LED torch lamp function · Sampling rate: 3 times per second · CAT III 600 V overvoltage protection
· CAT IV 600 V · Auto power-off function · IEC/EN 61010-1 (DIN VDE 0411)
· TÜV/GS tested and approved · CAT III 300 V · Including batteries, measurement leads and carrying
· IEC/EN 61010-1 (DIN VDE 0411) · TÜV/GS tested and approved bag
· IEC/EN 61010-1 (DIN VDE 0411) 12
