Page 238 - Destaco - Clamping Technology

8215_C
8000, 8200, 8400 series

Pneumatic Swing Clamps | Dimensions
SERIES 8200 SERIES 8000, 8400
Ø D4 Ø M1
H5
Ø D3
Ø D4
H6
L1
L4 Ø D1

M3
Ø D1

L3 L2
Ø D2
H2

H1

H4

M2

H3

mm [INCH] mm [INCH]

THIRD ANGLE FIRST ANGLE
M PROJECTION PROJECTION
Model ØD1 ØD2 ØD3 ØD4 H1 H2 H3 H4 H5 H6 L1 L2
8015 [1.25] [0.44] -- -- [0.53] [0.41] [2.87] [0.50] [0.75] -- -- [1.12]
8016 31,8 11,1 13,5 10,4 72,9 12,7 19,1 28,4
8215 [3.00] [0.28] [2.66] [0.97] [0.81] [3.36] [0.25] [1.16] [2.00]
8216 76,2 [0.50] 7,1 67,6 24,6 20,6 85,3 [0.75] [0.67] 6,4 29,5 50,8
8415 [2.13] 12,7 -- -- [0.94] [0.78] [3.17] 19,1 17 -- -- [1.56]
8416 54,1 23,9 19,8 80,5 39,6

Model L3 L4 M M1 M2 M3
8015 [0.31] [0.62] 1-1/8-16 ¼-20 #10-32 #10-32
8016 7,9 15,7
8215 2-1/4-12
8216 [0.38] [0.75]
8415 9,6 19,1 1-3/4-12 5/16-18 1/8 NPT 3/8-16
8416
Mounting Options

8000, 8200, 8400 8200 only
Mounted into a tapped Mounted through a
hole or a through a clearance hole using
clearance hole with mounting screws in
the optional mounting the top flange.
flange. Jam nuts are
available for 8000.

MC-PSC-29 Dimensions and technical information are subject to change without notice
