Chapter 36: Working with Function Curves in the Track View
TABLE 36.5
Controllers Toolbar Buttons
Name
Toolbar Button
Filters
Opens the Filter dialog box, where you can specify which tracks
will appear; same button as found in the Keys toolbar
Copies the selected track for pasting elsewhere
Copy Controller
Paste Controller Description
Pastes the last copied track
Assign Controller Enables you to assign a controller to the selected track
Delete Controller Removes the current controller
Make Controller Unique Changes an instanced track to one that is unique

Tools toolbar
The Tools toolbar is available in the Curve Editor and includes buttons to add some additional tracks, such
as the Notes and Visibility. Table 36.6 describes these buttons.

TABLE 36.6
Tools Toolbar Buttons

Toolbar Button Name Description
Add Note Track Adds a note track to the current track for recording information

Delete Note Track Deletes an associated note track

Add Visibility Track Adds a track to an object for controlling its visibility

Snap Frames Causes moved tracks to snap to the nearest frame; also found in the
Curves toolbar
Lock Selection Locks the current selection of keys so that no other keys can be selected

Properties Displays a dialog box of properties associated with the track

Track View Utilities Opens a dialog box of available Track View utilities

887
