Part VIII: Advanced Animation Techniques
Biped toolbar
The Biped toolbar is available only in the Curve Editor and includes buttons to display the various biped
tracks. Table 36.7 describes these buttons.
TABLE 36.7
Toolbar Button Name Biped Toolbar Buttons
Description
Show Biped Position Curves Displays the position curves for the selected biped
Show Biped Rotation Curves Displays the rotation curves for the selected biped
Show Biped X Curves Displays the X-axis curves for the selected biped
Show Biped Y Curves Displays the Y-axis curves for the selected biped

Show Biped Z Curves Displays the Z-axis curves for the selected biped

Other toolbars
The Dope Sheet layout includes two additional toolbars: Ranges and Extras. Table 36.8 describes these
buttons.

TABLE 36.8
Ranges and Extras Toolbar Buttons

Toolbar Button Name Description
Edit Ranges Enables edit ranges mode; same button as found in the Keys toolbar

Position Ranges Enables position ranges mode

Recouple Ranges Lines up the keys with the range

Exclude Left End Point Leaves the left end point out of the current time block

Exclude Right End Point Leaves the right end point out of the current time block

888
