33-1
Transmission axle-transmission axle assembly
Transmission axle assembly

Malfunction symptom table

Use the table below to help you find the cause of the Malfunction. The numbers indicate the probability
of the cause of the Malfunction. Check each part in order. If necessary, replace these parts.

Symptom Suspect Area Reference
1. Transmission axle (Loose) Chapter 33 transmission axle-transmission axle
assembly, replacement
2. Lubrication (Insufficient) -
3. Universal joint (Worn or damaged) Chapter 33 transmission axle- universal joint,
overhaul
Noise from
transmission axle 4. Intermediate bearing (Worn or damaged) Chapter 33 transmission axle- intermediate
bearing, overhaul
Chapter 33 transmission axle- transmission axle
5. Sliding spline (Worn) assembly, inspection
Chapter 33 transmission axle- sliding yoke,
replacement

1. Transmission axle (Loose) Chapter 33 transmission axle- transmission axle
assembly, replacement

2. Transmission axle (The marks are not aligned) Chapter 33 transmission axle- transmission axle
assembly, replacement
3. Transmission axle (Distorted or bent)
Chapter 33 transmission axle- transmission axle
Transmission axle assembly, inspection
vibrates 4. Transmission axle (Unbalanced) Chapter 33 transmission axle- transmission axle
5. Rubber gasket ring of intermediate bearing assembly, on-vehicle inspection 33
(Aged or damaged) Chapter 33 transmission axle- intermediate
6. Intermediate bearing (Worn or damaged) bearing, overhaul
Chapter 33 transmission axle- intermediate
bearing, overhaul

1. Parking brake (Used frequently during the -
driving)
The intermediate CHAPTER 33 TRANSMISSION AXLE-
axle heats up 2. Intermediate bearing bracket (Not straight) INTERMEDIATE BEARING, OVERHAUL
3. Lubrication (Insufficient)
-
