53-22
Battery-Battery

Fill

Notes:
The protective appliance must be worn before filling the electrolyte. Wet the clothes with
10% carbonated water solution immediately if sulfuric acid is plashed onto clothes and then
wash it by clean water.

1. Fill in acid
(a). Take off vent cap; the ventilation hole on the cap must be penetrated, and take away the seal
gasket and seal paper under the vent cap after filling.
(b). The electrolyte can be filled into battery only when its temperature reaches to below 30 ℃.
(c). Fill the electrolyte into every cell, and make the level of electrolyte align with the “max”
mark on housing; in the rubber groove, the level of electrolyte should be 10-15mm higher
than separator.
(d). Fasten the vent cap and prevent acid leaking.

Hint:
For the discharged drained battery, it is a must to be initial charged after filling the acid (refer to
“Chapter 53 Battery-Battery, Application and maintenance”). For the dry charged battery, it can be
used half an hour later after filling the acid and needs not to be initial charged; but it is better charge
it 3-4 hours which is better for battery performance.
