Circuit-System circuit diagram

Service hint
z B015 Switch of brake lamp
1-2: the switch will be closed when the vehicle is at brake state.

: Part position

Reference wire Reference wire Reference wire
S/N S/N S/N
harness harness harness
B015 Body wire C003 Chassis wire J002 Chassis rear wire
B050 Body wire C051 Chassis wire J005 Chassis rear wire

: Insert parts between wire harnesses

S/N S/N Reference wire harness (position of the insert parts)
B103 C101 Body wire and chassis wire (middle of the first cross member of frame)

C106 B104 Body wire and chassis wire (middle of the first cross member of frame)
C102 J101 Chassis wire and chassis rear wire (rear side of frame right side member)

: Grounding

S/N Grounding position
A206 Right side of instrument panel is grounded
B207 Right side of front panel is grounded
C237 Chassis wire harness is grounded
C238 Chassis wire harness is grounded
