Circuit-System circuit diagram

Service hint
z L001 Switch of left door lamp; H001 Switch of right door lamp.
1-grounding: the switch will be closed when the door is opened.

: Part position

Reference wire Reference wire Reference wire
S/N S/N S/N
harness harness harness
B050 Body wire F002 Ceiling wire L001 Wire of left door

Wire of right
C051 Chassis wire H001
door
: Insert parts between wire harnesses

S/N S/N Reference wire harness (position of the insert parts)
B103 C101 Body wire and chassis wire (middle of the first cross member of frame)
F101 B112 Ceiling wire and body wire (left side of instrument panel)
H101 B102 Wire of right floor and body wire (right side of washing pot under right side of meter)
L101 B110 Wire of left floor and body wire (at the position of clutch pedal under left side of meter)
