73-1
Instrument panel/Combined meter/Cigar lighter-Instrument panel

Instrument panel

Notices

1. Please release the air pressure inside of brake system before the instrument panel is
disassembled.
(a). Align wheel to right ahead.
(b). Fix 4 wheels by wedge block.
(c). Apply parking brake.
(d). Ignition switch: ON.
(e). Step down brake pedal repeated until the reading on pressure meter decreases to below
0.4MPa.

2. The disassembly of instrument panel will reset daily odometer and clock.

Hint:
Total odometer will not be reset.

3. The disassembly of instrument panel will make the audio system lose stored setting.

Hint:
The audio system needs to be reset after negative pole cable is connected. (refer to “Chinese and
English Application Manual of Audio System”).

4. Cutoff the power supply

(a). First disconnect the cable of battery negative pole before the disassembly/assembly of any
electric device and at the time of tools or devices may contact with the bare electric
terminals; this will prevent personnel or vehicle from hurt. 73
(b). The ignition switch must be turned off if there is no special explanation.
