73-4
Instrument panel/Combined meter/Cigar lighter-Instrument panel

6. Disassemble the filling port and cap of
brake fluid

7. Disassemble cruise switch +\- (refer to “Chapter 82 Cruise control- Cruise switch +\-,
Replacement”).
8. Disassemble the cruise switch (refer to “Chapter 82 Cruise control- Cruise switch +\-,
Replacement”).
9. Disassemble the combined meter assembly (refer to “Chapter 73, Instrument
panel/Combined meter/Cigar lighter-Combined meter, Replacement”).
10. Disassemble the central control panel assembly (refer to “Chapter 56 Audio
system-Audio unit, Replacement”)
11. Disassemble audio unit (refer to “Chapter 56 Audio system-Audio unit, Replacement”).
12. Disconnect the insert part of cigar
lighter.

73

13. Disassemble AC control mechanism
(a). Pull out 4 rod covers of the AC control
mechanism.
Hint:
Press the AC control mechanism at the same
time of pulling out rod covers.
