04-118
                                                 Diagnosis-illumination
                                                Diagnosis-Illumination
          3.     Checking harnesses

          (a)     Use a multimeter to measure resistances of harnesses between high beam relay R30/R31 and
                 left and right combination headlights.
                 Resistance: ≤2Ω
          (b)     Use a multimeter to measure resistance of harness between high beam relay R30/R31 and
                 ground.
                 Resistance: >1MΩ
          Are check results normal?
          Yes >   Replace bulbs.
          No >    Repair or replace harnesses.
