15-2
Exhaust-Exhaust pipe
1 Exhaust pipe joint clamp 17 Muffler clamp
2 Exhaust pipe welded unit 18 Type 1 hexagon nut
3 Hexagon bolt 19 Type 1 hexagon nut
4 Exhaust pipe support 20 Large washer
5 Type 1 hexagon nut 21 Rubber cushion
6 Spring washer 22 Bushing
7 Plain washer 23 Hanger plate
8 U-trim on roof 24 Hexagon bolt
9 Hexagon bolt 25 Rubber cushion
10 Hexagon flange bolt 26 Hexagon bolt
11 Plain washer 27 Type 1 hexagon nut
12 Type 1 hexagon nut 28 Spring washer
13 Exhaust processing unit 29 Plain washer
14 Type 1 hexagon nut 30 Support plate
15 15 Spring washer 31 Hexagon bolt
16 Plain washer 32 Secondary muffler assembly (optional)
