26-1
Braking-brake system

Brake system

Notes

1. Brake system operation notes
(a). Care must be taken to replace each part properly. Improper installation could affect the
performance of the brake system and result in person security
(b). Replace all parts with parts which are original pure parts.
(c). Keep all parts and the work area clean.
(d). Brake pipes are important safety parts, if a leak is detected, they must be repaired or
replaced if necessary.
(e). When opreate brake pipes, use a cap on the pipe orifice in order to prevent dust, dirt and
other foreign materials from entering into the pipe.
(f). Do not bend the brake pipes or deform them during the removal or installation.
(g). The buckles or cable tie removed can not be used again.
2. Brake system maintenance notes
(a). Inspect regularly, inspect the following parts every 5.000 Km.
• Inspect the clearance of brake shoe lining and brake drum.
• Inspect the brake shoe lining for wear.
• Inspect brake pedal stroke and pedal free play.
• Inspect the damage of brake pipes.
• Inspect the looseness of each connection.
• Inspect whether the functions of brake system are normal.

26
