Page 1822 - National Electrical Price Guide

National Electrical Price Guide

Assemblies
Feeder EMT & Wire D/C Set Screw Coup, Strap & Power 3" EMT 3#500, 1#1/0
Shot
Qty Description Labor Cost Retail
10 3" EMT 1.00 52.40 94.75
12 #1/0 THHN Stranded Copper .16 16.16 53.24
35 #500 THHN Stranded Copper 1.47 213.98 721.21
1 1" .300 Drive Pin .02 .07 .30
1 Red .25 Caliber Load .02 .11 .31
1 3" EMT 1 Hole Steel Strap .05 1.36 7.50
1 3" EMT Cast Set Screw Coupling .15 4.19 16.20
2.87 $288.28 $893.51
Feeder EMT & Wire D/C Set Screw Coup, Strap & Power 3" EMT 4#250
Shot
Qty Description Labor Cost Retail
10 3" EMT 1.00 52.40 94.75
46 #250 THHN Stranded Copper 1.10 139.33 478.69
1 Red .25 Caliber Load .02 .11 .31
1 1" .300 Drive Pin .02 .07 .30
1 3" EMT Cast Set Screw Coupling .15 4.19 16.20
1 3" EMT 1 Hole Steel Strap .05 1.36 7.50
2.34 $197.47 $597.75
Feeder EMT & Wire D/C Set Screw Coup, Strap & Power 3" EMT 4#250, 1#2
Shot
Qty Description Labor Cost Retail
10 3" EMT 1.00 52.40 94.75
12 #2 THHN Stranded Copper .12 10.50 35.25
46 #250 THHN Stranded Copper 1.10 139.33 478.69
1 Red .25 Caliber Load .02 .11 .31
1 1" .300 Drive Pin .02 .07 .30
1 3" EMT Cast Set Screw Coupling .15 4.19 16.20
1 3" EMT 1 Hole Steel Strap .05 1.36 7.50
2.46 $207.97 $633.00
Feeder EMT & Wire D/C Set Screw Coup, Strap & Power 3" EMT 4#300
Shot
Qty Description Labor Cost Retail
10 3" EMT 1.00 52.40 94.75
46 #300 THHN Stranded Copper 1.20 167.10 571.21
1 Red .25 Caliber Load .02 .11 .31
1 1" .300 Drive Pin .02 .07 .30
1 3" EMT Cast Set Screw Coupling .15 4.19 16.20
1 3" EMT 1 Hole Steel Strap .05 1.36 7.50
2.44 $225.23 $690.27
Feeder EMT & Wire D/C Set Screw Coup, Strap & Power 3" EMT 4#300, 1#2
Shot

Qty Description Labor Cost Retail
10 3" EMT 1.00 52.40 94.75
46 #300 THHN Stranded Copper 1.20 167.10 571.21
12 #2 THHN Stranded Copper .12 10.50 35.25
1 Red .25 Caliber Load .02 .11 .31
1 1" .300 Drive Pin .02 .07 .30
1 3" EMT Cast Set Screw Coupling .15 4.19 16.20
1 3" EMT 1 Hole Steel Strap .05 1.36 7.50
2.56 $235.73 $725.51

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
COPYRIGHT @ 1996-2019 by ELECTRICAL RESOURCES, INC.
