Tools for threads
Machine tap

Machine tap HSSE Ultra HL DIN 5156
For universal use up to 1000 N/mm2
Metal cutting tools
Metal cutting tools
CNC/conv.
G HSSE ULTRA
3xd HL B (3,5-5)
Application: Advantage:
For manufacturing pipe threads in through holes on ƒ Problem-solver where long service lives are
CNC or conventional machines in the steel, stain- required and materials that are difficult to process
less steel, NF metal, cast and special alloy material such as stainless steel are involved.
groups up to a strength of 1000 N/mm in single part ƒ Innovative cutting geometry and newly developed
2
and series production. ULTRA HL coating guarantee high process reli-
Execution: ability even under difficult machining conditions.
ƒ With transition-fit shank
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13208 18 12 8 11 10 19 19 17 19 17 18 13 18 7 6 6
Cutting material HSSE
Surface ULTRA HL
Tolerance of screw taps ISO 2 (6H)
Lead angle shape B
Application type/machine type CNC,
Conventional
Twist angle 0°
Coolant supply External
DIN 13208...
Ident. No.
mm mm mm mm mm
G 1/16 in 28 6.8 90 6 4.9 5156 005 O. R.
G 1/8 in 28 8.8 90 7 5.5 5156 010 O. R.
G 1/4 in 19 11.8 100 11 9 5156 020 O. R.
G 3/8 in 19 15.25 100 12 9 5156 030 O. R.
G 1/2 in 14 19 125 16 12 5156 040 O. R.
G 3/4 in 14 24.5 140 20 16 5156 060 O. R.
G 7/8 in 14 28.25 150 22 18 5156 070 O. R.
Unit price, €
Prod. Gr. 131
Machine tap HSSE
for universal use up to 1000 N/mm 2 DIN 5156

CNC/conv.
G HSSE
2,5xd C (2-3)
Application: Advantage:
No. 13378: For manufacturing pipe threads in ƒ Universal use for maximum flexibility in use.
through holes on CNC or conventional machines in ƒ No. 13378:
the steel, (stainless steel), NF metal and (cast) mate- ƒ Innovative cutting geometry for very high
rial groups up to a strength of 1000 N/mm in single dimensional accuracy, process reliability and
2
part and series production. chip removal.
No. 13379: For manufacturing pipe threads in blind ƒ High-quality, torsion-resistant HSSE cutting
holes on CNC or conventional machines in the steel, material and cutting edge finish for very high
(stainless steel), NF metal and (cast) material groups service life requirements.
up to a strength of 1000 N/mm in single part and ƒ No. 13379: Standard geometry with an excellent
2
series production. price-performance ratio
Execution:
ƒ With transition-fit shank
2
Application Steel (N/mm ) Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13379 16 12 9 18 18 15 18 15 15 13 16
Cutting material HSSE HSSE
Surface Vaporised Vaporised
Tolerance of screw taps ISO 2 (6H) ISO 2 (6H)
Lead angle shape C C
Application type/machine type CNC, CNC,
Conventional Conventional
Twist angle 40° (right) 40° (right)
Coolant supply External External
DIN 13378... 13379...
Ident. No. Ident. No.
mm mm mm mm mm
G 1/8 in 28 8.8 90 7 5.5 5156 010 O. R. 010 O. R.
G 1/4 in 19 11.8 100 11 9 5156 020 O. R. 020 O. R.
G 3/8 in 19 15.25 100 12 9 5156 030 O. R. 030 O. R.
G 1/2 in 14 19 125 16 12 5156 040 O. R. 040 O. R.
G 5/8 in 14 21 125 18 14.5 5156 050 O. R. 050 O. R.
