Milling tools
Cutters with indexable inserts
Milling cutter indexable inserts SN.X 1206..
for face milling cutters no. 16023
Metal cutting tools
scope of supply and services:
Packaging unit: 10 pieces
Ident. No. 270 Ident. No.
271–273
Surface Uncoated Coated Coated Coated
Carbide type HW4310 HC4410 HC4535 HC4630
Material to be processed Non-ferrous Steel, Cast Steel, Stain-
metal metal less steel Steel
Suitable for material group P
Suitable for material group M
Suitable for material group N
Suitable for material group K
Suitable for material group S
Suitable for material group H
ISO name Knife edge length (mm) Edge radius (mm) 16109... 16109... 16109... 16109...
ID no. ID no. ID no. ID no.
SNEX 1206 ANN-MA 12.7 2.36 270 O. R. - - - - - -
SNMX 1206 ANN-MM1 12.7 2.36 - - 271 O. R. 272 O. R. 273 O. R.
Unit price, €
Prod. group 156
Angular milling cutter, 90°, with thread
For AP... indexable milling inserts 1003..
Application: Wear-resistant, nickel-plated version
For universal use in all materials. With internal cooling
Execution: Clamping screw tightening torque (indexable D d
insert) M2.5 = 1.2 Nm
With screw-in thread
L2
L3
D (mm) L3 (mm) d max. ap (mm) Number of cutting Indexable insert Suitable for index- 16017...
edges (PCS) type able inserts ID no.
16 25 M8 9.3 2 21 AP.. 1003.. 160 O. R.
20 30 M10 9.3 3 21 AP.. 1003.. 161 O. R.
25 35 M12 9.3 4 21 AP.. 1003.. 162 O. R.
Unit price, €
Prod. group 108
