Milling tools
Cutters with indexable inserts

Surface Uncoated Coated Coated Coated Coated Coated Metal cutting tools
Carbide type HW4415 HC4535 HC4540 HC4615 HC4626 HC4635
Material to be processed Steel, Stain- Steel, Cast
Non-ferrous Steel, Stain- less steel, Steel metal, Steel, Cast
less steel,
Cast metal,
metal Special alloy Special alloy Hardened metal
material
Suitable for material group P ˜ ˜ ˜ ˜ ˜
Suitable for material group M ˜ ˜
Suitable for material group N ˜
Suitable for material group K š ˜ š
Suitable for material group S ˜ ˜
Suitable for material group H š
ISO name Knife edge length Edge radius (mm) Indexable insert 16109... 16109... 16109... 16109... 16109... 16109...
(mm) type ID no. ID no. ID no. ID no. ID no. ID no.
APHX 100304 10.5 0.4 21 103 O. R. - - - - - - - - - -
FR-ALU
APKT 1003 10.5 0.5 21 - - 095 O. R. - - 097 O. R. - - 099 O. R.
PDER-S
APKT 1003 11 0.5 22 - - - - 108 O. R. - - 109 O. R. - -
PDER-M
Unit price, €
Prod. group 156
Milling cutter indexable insert AP.. 10..
for indexable insert milling cutters no. 16017 / 16018 / 16055

scope of supply and services:
Box quantity: 10 pieces

Ident. No. Ident. No. 104 Ident. No.
100–102 105–107
Surface Uncoated Coated Coated Coated
Carbide type HW4410 HC4540 HC4410 HC4620
Material to be processed Steel, Stain-
less steel,
Non-ferrous
Non-ferrous Cast metal, metal, Cast Steel, Cast
metal Special metal metal
alloy
Suitable for material group P ˜ ˜
Suitable for material group M ˜
Suitable for material group N ˜ ˜
Suitable for material group K š ˜ š
Suitable for material group S ˜
Suitable for material group H
ISO name Knife edge length (mm) Edge radius (mm) Indexable insert type 16109... 16109... 16109... 16109...
ID no. ID no. ID no. ID no.
APKT 1003 PDER-M 11 0.5 21 104 O. R. - - - - - -
APKT 100308 PDER 11 0.8 22 - - 100 O. R. - - - -
APKT 100312 PDER 11 1.2 22 - - 101 O. R. - - - -
APKT 100320 PDER 11 2 22 - - 102 O. R. - - - -
APKT 1003 PDER-M 11 0.5 22 - - - - 105 O. R. 107 O. R.
Unit price, €
Prod. group 156
Drill/counter sink milling cutter, 90°, with Weldon shank
For AP... indexable milling inserts 1604..

Application: ƒ Clamping screw tightening torque (indexable
For drilling/countersinking in all materials. insert) M4 = 5.2 Nm
D d
Execution: Advantage:
ƒ With Weldon shank ƒ High cutting performance L2
ƒ Wear-resistant, nickel-plated version ƒ Safe chip removal thanks to positive cutting L3
ƒ Robust supports geometry
L1

D (mm) L3 (mm) L1 (mm) d (mm) max. ap (mm) Number of Number of in- Indexable Suitable for 16019...
cutting edges dexable inserts insert type indexable ID no.
(PCS) (PCS) inserts
32 50 130 32 30 2 3 27 AP.. 1604.. 010 O. R.
Unit price, €
Prod. group 108
