Page 328 - Buy Premium Tools ATORN Catalogue

Lathe tools
Indexable inserts ISO for lathe tools

VBMT indexable insert, positive
for longitudinal and copy lathing in stainless steel (special alloys)
Metal cutting tools
Metal cutting tools

Ident. No. Ident. No.
609–610 SM 650–651 FS
SP finishing SM finishing
Carbide type HC7520 HC7220
Machining conditions for indexable insert Medium Medium
Vc in stainless steel min./max. ˜ 80-210 m/ 120-230 m/
min min
Vc in special alloy min./max. ˜ 30-60 m/ 30-60 m/
min min
Chip breaker code ISO name min./max. ap f min./max. 17866... 17866...
ID no. ID no.
SM VBMT 160404-SM 0.3-2 mm 0.08-0.25 mm/U 609 O. R. - -
SM VBMT 160408-SM 0.6-2.5 mm 0.12-0.25 mm/U 610 O. R. - -
FS VBMT 110308-SS 0.5-1.6 mm 0.12-0.3 mm/U - - 650 O. R.
FS VBMT 160408-SS 0.6-2.5 mm 0.12-0.3 mm/U - - 651 O. R.
Unit price, €
Prod. group 156

www.buypremiumtools.com 328
