LOCKS

Flush Latches

ELECTRICAL

Flush Latches — Smooth Silk Finish Black Lever Latch with Flag Indicator

„ Grip range 0 – 21 mm „ Die cast zinc – black powder „ A specialised lever latch designed to indicate whether the
„ With mounting bracket in coated. Silk Finish latch has been operated since it was last reset with the
position width B is 41mm „ Part No. 3215A Non-locking supplied key.
overall „ Part No. 3225A Locking „ Green indicates the latch has not been operated
„ Red indicates the latch has been operated EMERGENCY
„ Smooth silk powder coat finish

GENERAL

D
C
HANDLES

A

B E
Part No. A B C D E Kg Finish Part No. A B C D E Type Kg Finish HINGES
3215A 93 34 16 35 22 0.185 BPCZ 3225BS 93 34 16 35 22 Locking 0.19 BPCZ
3225A 93 34 16 35 22 0.19 BPCZ 3215BS 93 34 16 35 22 Non Locking 0.17 BPCZ

Thumb Turn Compression Latch — Key Slot Drive Compression Latch IRONWORK
Locking
„ Widely used in the transport industry
„ Key Locking Thumb „ Colour Black Powder Coated
„ Turn Compression Latch „ Head Style Slotted Recess
„ Widely used in the transport industry Colour Black Powder „ Supplied with spur washers and two cams for differing grip
Coated Head Style Wing ranges
„ Supplied with spur washers and two cams for differing grip „ Material Zinc Alloy LIGHTING
ranges
„ Material Zinc Alloy
„ Grip Type Adjustable

LOCKS

B
B STEPS

A A
E E D
C D C

Part No. A B C D E Kg Finish Part No. A B C D E Kg Finish VENTILATION
3640-1 56 92 70 14 22 0.24 BPCZ 3640 28 5 70 14 22 0.165 BPCZ
